Model: TYSC135
Motor installation mode; Directly connected type
Screw diameter: 50mm
Lead of lead screw: 5mm,10mm,25mm,50mm
Effective stroke: 0-2000mm
Rated output: 20/50KN
Motor power: 1KW/2KW/3KW/5KW/7.5KW
Rated speed: 250mm/s，500mm/s,1000mm/s
Repeated positioning accuracy: ±0.02mm
Protection class: IP65
Model: TYSC250
Motor installation mode; Directly connected type
Screw diameter: 100mm
Lead of lead screw: 20mm
Effective stroke: 0-3000mm
Rated output: 300KN
Motor power: 3KW/4KW/5.5KW/7.5KW/11KW
Rated speed: 250mm/s
Repeated positioning accuracy: ±0.02mm
Protection class: IP65
Model: TYSC270
Motor installation mode; Directly connected type
Screw diameter: 100mm
Lead of lead screw: 25mm
Effective stroke: 0-3000mm
Rated output: 400KN
Motor power: 3KW/4KW/5.5KW/7.5KW/11KW
Rated speed: 250mm/s
Repeated positioning accuracy: ±0.02mm
Protection class: IP65
Model: TYSC320
Motor installation mode; Directly connected type
Screw diameter: 125mm
Lead of lead screw: 25mm
Effective stroke: 0-3000mm
Rated output: 600KN
Motor power: 5.5KW/7.5KW/11KW/15KW/22KW
Rated speed: 150mm/s
Repeated positioning accuracy: ±0.02mm
Protection class: IP65
Model: TYSC220
Motor installation mode; Directly connected type
Screw diameter: 80mm
Lead of lead screw: 20mm
Effective stroke: 0-3000mm
Rated output: 200KN
Motor power: 3KW/4KW/1KW/2KW
Rated speed: 250mm/s
Repeated positioning accuracy: ±0.02mm
Protection class: IP65
Model: TYSC110
Motor installation mode; Directly connected type
Screw diameter: 32mm
Lead of lead screw: 5mm,10mm,25mm,32mm
Effective stroke: 0-2000mm
Rated output: 1.6/2/1.5/1.4KN
Motor power: 0.75KW/1KW/2KW/3KW
Rated speed: 250mm/s，500mm/s,1000mm/s,1600mm/s
Repeated positioning accuracy: ±0.02mm
Protection class: IP65
Model: TYSC095
Motor installation mode; Directly connected type
Screw diameter: 25mm
Lead of lead screw: 5mm,10mm,25mm
Effective stroke: 0-1500mm
Rated output: 15KN
Motor power: 0.4KW/0.75KW/1KW/2KW
Rated speed: 250mm/s，500mm/s,1250mm/s
Repeated positioning accuracy: ±0.02mm
Protection class: IP65
Model: TYSC050
Motor installation mode; Directly connected type
Screw diameter: 16mm
Lead of lead screw: 5mm,10mm
Effective stroke: 0-500mm
Rated output: 0.5KN
Motor power: 0.1KW/0.2KW
Rated speed: 250mm/s，500mm/s
Repeated positioning accuracy: ±0.02mm
Protection class: IP65
Model: TYSC075
Motor installation mode; Directly connected type
Screw diameter: 20mm
Lead of lead screw: 5mm,10mm,20mm
Effective stroke: 0-1500mm
Rated output: 5KN
Motor power: 0.4KW/0.75KW/1KW
Rated speed: 250mm/s，500mm/s,1000mm/s
Repeated positioning accuracy: ±0.02mm
Protection class: IP65
Model: TYSC065
Motor installation mode; Directly connected type
Screw diameter: 16mm
Lead of lead screw: 5mm,10mm,16mm,20mm
Effective stroke: 0-1000mm
Rated output: 3KN
Motor power: 0.1KW/0.2KW/0.4KW
Rated speed: 250mm/s，500mm/s
Repeated positioning accuracy: ±0.02mm
Protection class: IP65
Model: TYSC045
Motor installation mode; Directly connected type
Screw diameter: 12mm
Lead of lead screw: 5mm
Effective stroke: 0-300mm
Rated output: 0.4KN
Motor power: 0.1KW
Rated speed: 200mm/s
Repeated positioning accuracy: ±0.02mm
Protection class: IP65
Model: TYSC026
Motor installation mode; Directly connected type
Screw diameter: 8mm
Lead of lead screw: 2.5mm
Effective stroke: 0-100mm
Rated output: 0.2KN
Motor power: 0.05KW
Rated speed: 125mm/s
Repeated positioning accuracy: ±0.02mm
Protection class: IP65
